Open Frame Diesel Generator Set with 15 Kw Standby Power and 1500 R/min Rated Speed

Open Frame Diesel Generator Set with 15 Kw Standby Power and 1500 R/min Rated Speed
Open Frame Diesel Generator Set with 15 Kw Standby Power and 1500 R/min Rated Speed Open Frame Diesel Generator Set with 15 Kw Standby Power and 1500 R/min Rated Speed Open Frame Diesel Generator Set with 15 Kw Standby Power and 1500 R/min Rated Speed
Basic Information
Brand Name: DEHRAY
Certification: CE EU5
Model Number: RDE19STA3
Minimum Order Quantity: 1 Set
Delivery Time: 2 Weeks
Payment Terms: TT
Get Best Price Chat Now
Rated Voltage: 400/230 V Engine Brand: Yanggdong
Max Power: 18.5 Kva Engine Model: YND485D
Standby Power: 15 Kw Rated Rotation Speed: 1500 R/min
Genset Dimension: 1505×785×1055 Mm Prime Power: 14 Kw
Highlight:

open frame diesel generator set

,

1500 rpm diesel generator

,

commercial diesel genset 1505x785x1055mm

Diesel Generator Set Overview
This robust 15 kW standby power diesel generator set delivers reliable electricity for industrial, commercial, and residential applications. Engineered with a 3-phase FD1ES1-4 alternator and premium WEICHAI or YUCHAI engine options, it ensures stable power output with operational flexibility at 1500/3000 R/min rotation speeds.
Key Features
  • Diesel Generator Set with 18.5 KVA maximum power
  • 24.5 A rated current for stable performance
  • YND485D engine model with reliable operation
  • 75 DB(A) noise level at 7 meters distance
  • Faraday alternator brand for quality power generation
  • Intelligent control system for efficient operation
  • Three-phase power output for industrial applications
  • General purpose design suitable for various uses
Technical Specifications
Structure Type 4-cylinder, In-lined, 4-stroke, Direct-injected, Water-cooled
Excitation Mode Brushless, Self-excitation And Constant Voltage (with AVR)
Standby Power 15 kW
Prime Power 14 kW
Rated Power 17 kVA
Rated Voltage 400/230 V
Fuel Tank Capacity 100 L
Genset Dimensions 1505 × 785 × 1055 mm
Engine Model YND485D (YANGDONG Engine)
Additional Features Electric Starter, Waterproof, Dustproof, Sand proof and Rodent proof design
Applications
The DEHRAY RDE19STA3 Diesel Generator Set is CE EU5 certified and ideal for construction sites, industrial operations, agricultural fields, outdoor events, and emergency backup power. Its rugged waterproof, dustproof, sand proof, and rodent proof design ensures reliable performance in challenging environments.
Support & Services
Our comprehensive technical support includes installation guidance, routine maintenance, troubleshooting, and repair services. We provide detailed documentation, customized service plans, and staff training programs to ensure optimal performance and extended equipment lifespan.
Quick Specifications: 15 kW standby power • 100L fuel capacity • 630 kg net weight • 1505×785×1055 mm dimensions • Flexible 1500/3000 R/min operation
