| Place of Origin: | China |
|---|---|
| Brand Name: | Dehray |
| Certification: | CE |
| Model Number: | 6500T |
| Minimum Order Quantity: | 1 |
| Price: | USD |
| Packaging Details: | Plywood board + corrugated box |
| Delivery Time: | 2 weeks |
| Payment Terms: | T/T,L/C,Western Union |
| Supply Ability: | 1 per week |
| Features: | Portable, Easy To Use | Voltage: | 230/400V |
|---|---|---|---|
| Power Source: | Manual | Material: | Metal |
| Package Contents: | One Generator, Instruction Manual | Cooling System: | Cooling Water Tank/cooling Tower |
| Compatibility: | Universal | Rated Rotation Speed: | 3000/3600 Rpm |
| Model: | RDE6500T3 | Generator Type: | Diesel |
| Model No: | RDE6500T | Warranty: | 1 Year |
| Max Power: | 6.5KVA | Rated Speed: | 3000r/min |
| Rated Frequency: | 50Hz | ||
| Highlight: | 6KW Portable Generator,230/400V Diesel Generator Set,15L Fuel Capacity Generator |
||
| Parameter | 6500T |
|---|---|
| Rated frequency | 50 Hz / 60 Hz |
| Prime power | 5.5 kVA |
| Max. power | 6.5 kVA |
| Rated voltage | 230 V (50Hz) / 120/240 V (60Hz) |
| Rated current | 23.9 A (50Hz) / 46.8/23.4 A (60Hz) |
| Rated rotation speed | 1500 r/min (50Hz) / 1800 r/min (60Hz) |
| DC output | 12V-8.3A |
| Power factor (COSΦ) | 0.8 (lagging) |
| Phase number | Single phase |
| Engine type | 4-stroke, single-cylinder, air-cooled diesel engine |
| Engine model | R186FA |
| Displacement | 0.499 L |
| Compression ratio | 19.0∶1 |
| Engine rated power | 7.5 kW / 1500 r/min |
| Lube oil brand | Above CD grade, SAE 10W-30 / 15W-40 |
| Lube oil capacity | 1.6 L |
| Ignition system | Compression ignition |
| Starting system | Recoil starter (electric start optional) |
| Fuel type | Diesel (0# / -10# / -20# according to ambient temperature) |
| Lowest fuel consumption | 235 g/kW.h |
| Fuel tank capacity | 15 L |
| Continuous running time (rated output) | 10 h |
| Noise level (unload-full load, 7m) | 60-72 dB(A) |
| Overall dimensions (L×W×H) | 910×530×740 mm |
| Net weight | 140 kg |
| Key certifications | CE, ISO9001, EU V |
